JRC JMA-9822-6XA User Manual

1 – 5
1.3 CONFIGURATION
Scanners and Transmitted Output Powers
Radar Configuration and Ship’s Mains
Note: JMA-9833-SA, 220 V AC, 50/60 Hz, 1Ø ··· MED only
Radar Model Scanner Type Transmitted Output Power Band
JMA-9833-SA 12 ft slot antenna 30 kW S
JMA-9832-SA 12 ft slot antenna 30 kW S
JMA-9823-7XA 7 ft slot antenna 25 kW X
JMA-9823-9XA 9 ft slot antenna 25 kW X
JMA-9822-6XA 6 ft slot antenna 25 kW X
JMA-9822-9XA 9 ft slot antenna 25 kW X
Radar Model Scanner Unit Performance
Monitor
Transmitter-
receiver
Unit
Display Unit
Ship’s Mains
JMA-9833-SA NKE-1079 (*) NJU-63 NTG-3037
NCD-4111
220 V AC, 50/60 Hz, 3ø
110/220 V AC, 50/60 Hz, 1ø
JMA-9832-SA NKE-1075 (*) NJU-63
JMA-9823-7XA NKE-1059-7 (*)
NJU-64 NTG-3027
JMA-9823-9XA NKE-1059-9 (*)
JMA-9822-6XA NKE-1052-6 (*)
NJU-64
JMA-9822-9XA NKE-1052-9 (*)
