11.4 JMA-9822-6XA/9XA TYPE RADAR

...

.....

……11.4 JMA-9822-6XA/9XA TYPE RADAR …………………………

■ General Specification

(1) Type of Emission: P0N

(2) Display: Color Raster Scan

(3) Screen: 29-inch Color CRT (Effective Diameter, more than 340 mm)

(4) Range Scale: 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48 and 96 (or 120) NM

(5) Range Resolutition: Less than 30 m

(6) Minimum Detective Range: Less than 25 m

(7) Bearing Accuracy: Less than 1˚

(8) Bearing Indication: North-up/Head-up/Course-up

(9) Ambient Condition: Temperature

Scanner: -25˚C to +55˚C

(Strage Temperature: -25˚C to +70˚C)

Other Units except Scanner: -15˚C to +55˚C

Relative Humidity 93% at +40˚C

(10) Vibration: 2 to 13.2 Hz, amplitude ±1 mm ±10%

13.2 to 100 Hz, max. acceleration 7 m/s

constant

(11) Power Supply Input: Scanner: 220 V AC, 50/60 Hz, 3ø

110/220 V AC, 50/60 Hz, 1ø

(12) Power Consumption: Approx. 800 VA

(13) Power Supply Input Voltage

Fluctuation: Input Voltage ±10% (at the maximum cable length)

(14) Pre-heating Time: Within 4 min

(15) From Standby up to Operation: Within 15 sec

■ Scanner (NKE-1052-6/9) See 11.8

■ Display Unit (NCD-4111) See 11.11

■ Performance Monitor (NJU-64) See 11.14

■ Option

(1) Scanner with Deicing Heater: NKE-1052-6D/9D (only heater collar)

(2) Radar Interswitch: NQE-3015N

(3) Display Unit (Desktop Type) NCD-4111-T

■ Distance between Units Maximum Distance

(1) Scanner - Display: 50 m

■ Compass Safety Distance Standard

(1) Scanner: 2.4 m

(2) Display: 3.2 m
