3 – 40
3
3.4 BASIC OPERATIONS
.
..
……Use EBLs (Electronic Bearing Lines) ……………………………
The EBLs (Electronic Bearing Lines) are indispensable to measure distances and bearings of
targets.
Before operation, the operator must be familiar with the operation of EBLs.
EBL1 Operation
If EBL2 is selected, press to select EBL1 before operation. (The currently selected
EBL is indicated by selected characters in the lower right of the radar display.)
Press . EBL1 will be selected EBL1 will operate
Press . EBL1 will disappear
EBL2 Operation
If EBL1 is selected, press to select EBL2 before operation. (The currently selected
EBL is indicated by selected characters in the lower right of the radar display.)
Press . EBL2 will be selected EBL2 will operate
Press . EBL2 will disappear
To Next Page
