5 – 20
5
5.6 DATA DISPLAY
……Types of Data Display ………………………………………………
Target Data
The target for which its numeric data is displayed is marked with a symbol “” to distinguish from
other targets.
……Method of Displaying Target Data TGT DATA …………………
1 Press .
will appear in the CURSOR ( ) at the upper right of the radar display.
2 Move the cross cursor mark to a target (under tracking) to indicate its data using the
trackball. Then, press trackball section left button or to set its entry.
(Up to 2 targets settable)
Procedures
If a target’s data is displayed, but without the symbol “”, such a target exists outside the
currently displayed radar display.
Note
● When a target or own ship changes its course, or when a new target is acquired, its vector may
not reach a given level of accuracy until three minutes or more has passed after such course
change or target acquisition.
Even if three minutes or more has passed, the vector may include an error depending upon the
tracking conditions.
Attention
Target identification (ID) ID number of the target
True bearing: BRG 1˚ unit
Range: RNG 0.1 NM unit
True course: CSE 1˚ unit
True speed: SPD 0.1 knot unit
Closest point of approach (CPA) 0.1 NM unit
Time to CPA (TCPA) 0.1 min unit
Bow crossing range (BCR) 0.1 NM unit
Bow crossing time (BCT) 0.1 min unit
T
T
T
