JRC JMA-9822-6XA User Manual

5 – 3
4 Display the CPA LIMIT ring.
(1) Press .
“ON” in “3.CPA RING” will be set and “”
will appear on the radar display.
(2) Should the CPA ring not appear, press .
“OFF” in “3.CPA RING” will be set.
Note: The CPA RING is not appear in the TRUE Vector
mode.
5 Set TCPA LIMIT (Time to CPA).
(1) Press .
will be selected.
(2) Enter a value using the ten-key.
(3) Press to set up the value entry.
1 Press .
The Sub1 Menu will reappear.
2 Press .
The Sub1 Menu will be closed.
Note: The set values of CPA LIMIT/TCPA LIMIT will appear on the radar display.
0
0
Exit
ENT
2.TCPA LIMIT
2
3
CPA RING
3
SUB1 MENU
ARPA
2.TCPA LIMIT
1.CPA LIMIT
0.1-9.9nm
1-99min
0.
EXIT
3.CPA RING
1.5
10
OFF ON
5.GATE
4.
TRIAL
2. NARROW
SUB1 MENU
ARPA
2.TCPA LIMIT
1.CPA LIMIT
0.1-9.9nm
1-99min
0.
EXIT
3.CPA RING
1.5
10
OFF ON
5.GATE
4.
TRIAL
2. NARROW
