5 – 10
5
5.4 TARGET ACQUISITION
..
...
When the guard zone is set, it will be ON by pressing .
Press again, and the automatic acquisition mode will be set to OFF and the guard zone
will disappear from the radar display. However, the target ships that have been acquired automatically
will be tracked continuously.
Guard Zone
Target that has entered the guard zone.
The guard zone intruder symbol is displayed.
Target that has intruded the guard zone for 1 min.
The guard zone intruded symbol, captured symbol and
vector are displayed.
Target that has moved outside the guard zone.
The capture symbol and vector are displayed.
The guard zone intruder symbol is cleared.
