5 – 16
5
5.5 ARPA DATA DISPLAY
..
...
[
22
] Vector Length: VECTOR TIME
The vector length of a target is proportional to its speed, and the vector time can be changed over in a
range of 1 to 60 minutes by used for ten-key.
The diagram below illustrates a vector length of a target for six minutes, and the tip of the vector
represents the target’s position expected to reach six minutes later.
Setting Vector Time
1 Press .
The VECTOR TIME Menu will appear.
2 Set a vector time using
and . (Unit: minute)
(When depressing or continuously,
the vector time will be change rapidly.)
The vector time will appear at upper right of the radar display.
or,
1 Press from the VECTOR TIME Menu.
2 Use the ten-key to enter the vector time.
3 Press to enter the setting.
ENT
1
Procedures
-
+
-
+
VECT
TIME
Procedures
VECTOR TIME
1.VECTOR TIME
1-60min
0.
EXIT
6
