7 – 3
(1) Radiator
Check up and clean the radiator.
Bolt (Stainless steel) 4-M8
Proper Tightening Torque: 1176 to 1470 N•cm
(120 to 150 kgf•cm)
Cover of NKE-1059/1052
Bolt Tightening Procedure
Cover of NKE-1079/1075
Bolt Tightening Procedure
Bolt (Stainless steel) 8-M8
Proper Tightening Torque: 1176 to 1470 N•cm
(120 to 150 kgf•cm)
q
r
e
w
tqu
iwy
er
● If the radiator front face (radiation plane) is soiled with smoke, salt, dust, paint or birds’
droppings, wipe it with a piece of soft cloth wetted with alcohol or water and try to keep it clean
at all times. Otherwise, radar beam radiation may attenuate or reflect on it, resulting in
deterioration of radar performance.
● Never use solvents of gasoline, benzine, trichloroethylene and ketone for cleaning. Otherwise,
the radiation plane may deteriorate.
Attention
To Next Page
