8
–
11
1
Press .
The TEST Menu will reappear.
2
Press .
The TEST Menu will be closed.
(7) System Information Display
The current system information will be indicated.
1
Press .
The TEST Menu will appear.
2
Press .
The SYSTEM INFO Menu will appear and the current system information will appear.
1
Press .
The TEST Menu will reappear.
0
Exit
Ver. 01.00
TEST MENU
SYSTEM INFO
Ver. 02.10
No. 01.00
1 hours
2 hours
0.
EXIT
7
TEST
Procedures
0
0
Exit
253
255
