8.3 COUNTERMEASURES TO TROUBLE
.
...
....
8
Table 8.9 Special Parts
[
11
] JMA-9833-SA
[
22
] JMA-9832-SA
[
33
] JMA-9823-7XA/9XA
[
44
] JMA-9822-6XA/9XA
Parts No. Name Type Manufacturer Location Code
V1 Magnetron M1437(A) NJRC Transmitter- 5VMAA00074
receiver
A201/A202 Circulator FCX68 Toshiba Transmitter- 6AJRD00001
receiver
A203 Diode Limiter NJS6928 NJRC Transmitter- 5EZAA00019
receiver
A302 Pin Attenuator NJS6926 NJRC Transmitter- 5ENAC00019
receiver
Parts No. Name Type Manufacturer Location Code
V101 Magnetron M1302 NJRC Scanner 5VMAA00032
A101 Circulator NJC3320 NJRC Scanner 5AJBV00004
A303 TRHPL TL378A NJRC Scanner 5VLAA00032
Parts No. Name Type Manufacturer Location Code
V1 Magnetron M1437(A) NJRC Scanner 5VMAA00074
A101 Circulator FCX68 Toshiba Scanner 6AJRD00001
A303 Diode Limiter NJS6928 NJRC Scanner 5EZAA00019
A302 Pin Attenuator NJS6926 NJRC Scanner 5ENAC00019
Parts No. Name Type Manufacturer Location Code
V201 Magnetron M1302 NJRC Transmitter- 5VMAA00032
receiver
A201 Circulator NJC3310 NJRC Transmitter- 5AJBV00002
receiver
A202 TRHPL TL378A NJRC Transmitter- 5VLAA00032
receiver
