8.3 COUNTERMEASURES TO TROUBLE
.
...
....
8
[
44
] JMA-9822-6XA/9XA
Location Circuit Block Type Remarks
Scanner Motor with gear MPEM30037 AC220V 3ø
Scanner Motor with gear MPEM30018 AC220V 1ø
Scanner Motor with gear MPEM30016 AC100/110V 1ø
Scanner Modulator NMA-441-1 Including PC210 (CPA-209)
Including PC220 (CBD-1226)
Excluding Magnetron
Scanner Receiver NRG-98 Including PC301 (CAE-344)
Scanner Rectifier circuit CBA-249 PC1001
Scanner T/R control circuit CMC-898 PC1101
Display Power supply circuit CBD-1514
Display Terminal board circuit CQD-1729
Display NSK/LOG I/F circuit CMJ-431
Display Display control circuit CMC-1096
Display Serial I/F circuit CHM-345
Display Keyboard process circuit CMD-835
Display Panel circuit-1 CCK-846
Display Panel circuit-2 CCK-847
Display Mother board CQC-969
Display Sensor circuit CHT-63
Display PCMCIA I/F circuit CMH-1715
Display Signal processing circuit CDC-1066
Display ARPA processor circuit CDC-1065
Display DSP MODULE 1 CDC-1073
Display DSP MODULE 2 CDC-1081
Display Monitor circuit CCN-326
Display Relay unit CSC-594
Display Interswitch circuit CCL-263 (Option)
