JRC JMA-9822-6XA User Manual

A – 4
APPENDIX
Table A-6 3-unit Type Scanner (X band) with Heater Collar (Option)
Type of Scanner NKE-1059-7D NKE-1059-7D NKE-1059-7D NKE-1059-9D NKE-1059-9D NKE-1059-9D
(110 V AC, 1ø) (220 V AC, 1ø) (220 V AC, 3ø) (110 V AC, 1ø) (220 V AC, 1ø) (220 V AC, 3ø)
Inner Antenna CQC-788 CQC-788 CQC-788 CQC-788 CQC-788 CQC-788
Driving Part CBP-122 CBP-132 CBP-132 CBP-122 CBP-122 CBP-132
Heater Controller CCK-750 CCK-750 CCK-750 CCK-750 CCK-750 CCK-750
Table A-7 2-unit Type Scanner (X band)
Type of Scanner NKE-1052-6 NKE-1052-6 NKE-1052-6 NKE-1052-9 NKE-1052-9 NKE-1052-9
(110 V AC, 1ø) (220 V AC, 1ø) (220 V AC, 3ø) (110 V AC, 1ø) (220 V AC, 1ø) (220 V AC, 3ø)
Inner Antenna CQC-683 CQC-683 CQC-683 CQC-683 CQC-683 CQC-683
Driving Part CBP-122 CBP-123 CBP-132 CBP-122 CBP-123 CBP-132
IF AMP circuit CAE-344 CAE-344 CAE-344 CAE-344 CAE-344 CAE-344
Inner Receiver Unit CMA-588 CMA-588 CMA-588 CMA-588 CMA-588 CMA-588
Modulator circuit CPA-209 CPA-209 CPA-209 CPA-209 CPA-209 CPA-209
MHPS circuit CBD-1226 CBD-1226 CBD-1226 CBD-1226 CBD-1226 CBD-1226
Inner Modulator Unit CNM-169 CNM-169 CNM-169 CNM-169 CNM-169 CNM-169
Filter circuit CFR-161 CFR-161 CFR-161 CFR-161 CFR-161 CFR-161
T/R control circuit CMC-898 CMC-898 CMC-898 CMC-898 CMC-898 CMC-898
Rectifier circuit CBA-249 CBA-249 CBA-249 CBA-249 CBA-249 CBA-249
Inner Transmitter-receiver Unit CQC-783 CQC-783 CQC-783 CQC-783 CQC-783 CQC-783
Table A-8 2-unit Type Scanner (X band) with Heater Collar (Option)
Type of Scanner NKE-1052-6D NKE-1052-6D NKE-1052-6D NKE-1052-9D NKE-1052-9D NKE-1052-9D
(110 V AC, 1ø) (220 V AC, 1ø) (220 V AC, 3ø) (110 V AC, 1ø) (220 V AC, 1ø) (220 V AC, 3ø)
Inner Antenna CQC-683 CQC-683 CQC-683 CQC-683 CQC-683 CQC-683
Driving Part CBP-122 CBP-123 CBP-132 CBP-122 CBP-123 CBP-132
Receiver Unit CAE-344 CAE-344 CAE-344 CAE-344 CAE-344 CAE-344
Inner Receiver Unit CMA-588 CMA-588 CMA-588 CMA-588 CMA-588 CMA-588
Modulator circuit CPA-209 CPA-209 CPA-209 CPA-209 CPA-209 CPA-209
MHPS circuit CBD-1226 CBD-1226 CBD-1226 CBD-1226 CBD-1226 CBD-1226
Inner Modulator Unit CNM-169 CNM-169 CNM-169 CNM-169 CNM-169 CNM-169
Filter circuit CFR-161 CFR-161 CFR-161 CFR-161 CFR-161 CFR-161
T/R control circuit CMC-898 CMC-898 CMC-898 CMC-898 CMC-898 CMC-898
Rectifier circuit CBA-249 CBA-249 CBA-249 CBA-249 CBA-249 CBA-249
Inner Transmitter-receiver Unit CQC-783 CQC-783 CQC-783 CQC-783 CQC-783 CQC-783
Heater Controller CCK-750 CCK-750 CCK-750 CCK-750 CCK-750 CCK-750
