A – 7
Table A-12 NDC-1097 Type Control Unit Circuit Compositions
Control Unit NDC-1097 JRC Code Remarks
1 Inner display unit CWB-1126
2 NSK/LOG I/F unit
NSK/LOG I/F circuit CMJ-431
3 Rack unit
Terminal board circuit CQD-1729
Display board circuit CMC-1096
Signal process circuit CDC-1066
DSP MODULE1 CDC-1073
DSP MODULE2 CDC-1081
Mother board CQC-969
ARPA process circuit CDC-1065
Serial I/F circuit CHM-345
4 Inner power supply unit
Power supply circuit CBD-1514
5 Relay unit CSC-594
6 Interswitch circuit CCL-263 (Option)
Table A-13 NCE-7292 Type Keyboard Unit Circuit Compositions
Keyboard Unit NCE-7292 JRC Code Remarks
1 Inner keyboard unit CWB-1125
Keyboard process circuit CMD-835
PCMCIA I/F circuit CMH-1715 (Option)
Panel circuit 1 CCK-846
Panel circuit 2 CCK-847
Sensor CHT-63
Table A-14 NWU-228 Type Monitor Unit Circuit Compositions
Monitor Unit NWU-228 JRC Code Remarks
1 Inner monitor unit
Monitor circuit CCN-326
