5.1.3 Analog inputs
The power controller has a voltage and a current input.
These inputs (default set point value) specify the required output at the load
output.
In most cases this signal is transmitted as a standard signal by an electronic
controller or a PLC and is adjusted with these settings.
1. Analog input inverting:
If, for example, 20mA is set for the start of the current measuring range and 0mA for
the end, the power controller is switched off at 20mA and switched on at 0 mA.
Value/settings Description
Current measuring
range
0 ... 20mA This setting specifies which standard current signal is to be
connected.
v Chapter 3.3 „Connection diagram“
4 ... 20mA
Customer specific
Current measuring
range, start
0 ...20mA Note: This parameter only appears when "Customer specific"
is set for the current measuring range (see above).
Current measuring
range, end
0 ...20mA Note: This parameter only appears when "Customer specific"
is set for the current measuring range (see above).
Voltage measuring
range
0 ... 10V This setting specifies which standard voltage signal is to be
connected.
v Chapter 3.3 „Connection diagram“
2 ...10V
0 ...5V
1 ... 5V
Customer specific
1
Voltage measuring
range, start
0 ...10V Note: This parameter only appears when "Customer specific"
is set for the voltage measuring range (see above).
Voltage measuring
range, end
0 ...10V Note: This parameter only appears when "Customer specific"
is set for the voltage measuring range (see above).
k / Bold = factory setting
