5 Configuration
5.1.8 Actual value output
The actual value output is an analog output at which different internal values
can be output as a standard signal.
5.1.9 RS422/485
Interface parameters for RS422/485 (see interface description B70.9061.2)
Value/settings Description
Signal type of
actual value output
The standard signal to be output at the actual value output is
set here.
Switched off No signal output at the actual value output.
0 ... 20mA
The "value to be output" is output in the form of a current
signal at the actual value output.
4 ...20mA
0 ... 10V
The "value to be output" is output in the form of a voltage
signal at the actual value output.
2 ...10V
0 ...5V
1 ... 5V
Value to be output
The value to be output at the actual value output is selected
here.
Load voltage Each of these values has to undergo a plausibility check.
Example:
Depending on the device type, the load voltage can be
between 0 and 500V.
As the signal range of 0 ... 9999.9 is factory set, the end value
must be adjusted to 500.0 to allow utilization of the full signal
range.
Load voltage
2
Load current
Load current
2
Power (in W)
Power (in W)
Resistance
Supply voltage
Device temperature
Set point value
Signal range
start value
0 ... 9999.9 Bottom limit for the "value to be output"
Signal range
end value
0 ... 9999.9 Top limit for the "value to be output"
k / Bold = factory setting
Value/settings Description
Baud rate
9600
19200
38400
Data format 8-1-none Data bits-stop bits-parity check
8-1-odd
8-1-even
8-2-none
Device address
1 ...255
Min. response time 0 ... 500ms
k / Bold = factory setting
