2011-07-01/00561073 [SCR Power Controller TYA202] 91
8 Fault messages and alarms
M/S incompatible
#0002...0008
- Different software versions for master
and slave
- Different power controller types used
(max. load current, load voltage and
cascade controls (if applicable) do not
match)
Use same power controller
types with same software ver-
sions.
#0002 Different device software versions Update devices to same soft-
ware versions
v Service hotline
#0003 VDN numbers of devices do not match Master/slave operation not pos-
sible
#0006 Different nominal voltages (device types)
of master and slave device.
Master/slave operation not pos-
sible
v Chapter 1.3 „Order specifi-
cations“
#0007 Different nominal currents (device types)
of master and slave device.
#0008 Set cascade control of the master is not
compatible with that of the slave device.
Change cascade controls of
both devices to U or U
2
.
Teach-in
load monitoring!
Reminder that "manual" teach-in has
been configured but not yet executed.
Perform teach-in
v Chapter 6.1 „Detection of
load faults“
Slave: limit value
Min. value reached
The value has gone below the set limit
value for the min. alarm.
Check why the value has gone
below the limit value.
Slave: limit value
Max. value reached
The set limit value for the max. alarm. has
been exceeded at the slave.
Check why the limit value has
been exceeded.
Slave: fault at
connected load
Break or short-circuit of a load resistor.
v Chapter 6.1 „Detection of load faults“
Replace defective heating ele-
ments.
Slave:
Fuse breakage
(red LED fuse is lit)
1. Semi-conductor fuse defective v Chapter 8.2 „Replace defec-
tive semi-conductor fuse“
2. No voltage at terminal U1 - Check wiring
- Check the line fuse for the
load circuit
Slave:
SCR breakage
SCR defective The device must be returned to
JUMO for repair.
h Return the device
Slave: SCR
short-circuit
SCR defective The device must be returned to
JUMO for repair.
h Return the device
Error message Cause Remedy
