Juniper EX9214 Hardware Guide

1.8 V 1830 mV
2.5 V 2526 mV
3.3 V 3338 mV
5.0 V 5059 mV
5.0 V RE 4969 mV
12.0 V 12239 mV
12.0 V RE 12123 mV
Power 2
4.6 V bias MidPlane 4840 mV
11.3 V bias PEM 11176 mV
11.3 V bias FPD 11292 mV
11.3 V bias POE 0 11272 mV
11.3 V bias POE 1 11311 mV
Bus Revision 64
FPGA Revision 13
PMBus Expected Measured Measured Calculated
device voltage voltage current power
XF ASIC A 1000 mV 997 mV 13625 mA 13584 mW
XF ASIC B 1000 mV 1000 mV 12484 mA 12484 mW
CB 1 status:
State Online Standby
Temperature 29 degrees C / 84 degrees F
Power 1
1.0 V 1002 mV
1.2 V 1214 mV
1.5 V 1472 mV
1.8 V 1807 mV
2.5 V 2520 mV
3.3 V 3319 mV
5.0 V 5059 mV
5.0 V RE 4969 mV
12.0 V 12258 mV
12.0 V RE 12239 mV
Power 2
4.6 V bias MidPlane 4840 mV
11.3 V bias PEM 11195 mV
11.3 V bias FPD 11234 mV
11.3 V bias POE 0 11176 mV
11.3 V bias POE 1 11214 mV
Bus Revision 64
FPGA Revision 13
PMBus Expected Measured Measured Calculated
device voltage voltage current power
