10. Bring the MIC online by pressing the power buon on the MIC unl the OK/FAIL LED on the MIC

is lit green. You can also bring the MIC online by issuing the following CLI command:

user@host> request chassis mic fpc-slot slot-number mic-slot slot-number online

Figure 84: Installing an EX9200-10XS-MIC or EX9200-20F-MIC

264
