Page #137 background imageLoading...
Page #137 background image
Appendix C
SRX100 Services Gateway Interface
Cable Specifications and Connector
Pinouts
This appendix includes the following sections:
Interface Cable and Wire Specifications for the SRX100 Services
Gateway on page 119
RJ-45 Connector Pinouts for the SRX100 Services Gateway Ethernet
Port on page 120
RJ-45 Connector Pinouts for the SRX100 Services Gateway Console
Port on page 120
Interface Cable and Wire Specifications for the SRX100 Services Gateway
Table 34 on page 119 lists the specifications for the cables that connect to ports.
Table 34: Cable and Wire Specifications for Ports
Device
Receptacle
Maximum
Length
Cable/Wire SuppliedCable SpecificationPort
RJ-456 ft (1.83 m)One 6-ft (1.83-m) length
with DB-9/DB-9
connectors
RS-232 (EIA-232) serial
cable
Console
port
RJ-45328 ft (100
m)
One 15-ft (4.57-m) length
with RJ-45/RJ-45
connectors
Category 5 cable or
equivalent suitable for
100Base-T operation
Ethernet
port
Related Topics RJ-45 Connector Pinouts for the SRX100 Services Gateway Ethernet Port on page
120
RJ-45 Connector Pinouts for the SRX100 Services Gateway Console Port on page
120
SRX100 Services Gateway Front Panel and Back Panel Views on page 6
Interface Cable and Wire Specifications for the SRX100 Services Gateway 119
