Chapter 2
SRX100 Services Gateway Hardware
Components and Specifications
This chapter includes the following sections:
■ SRX100 Services Gateway Specifications on page 5
■ SRX100 Services Gateway Front Panel and Back Panel Views on page 6
■ SRX100 Services Gateway Built-In Interfaces on page 8
■ SRX100 Services Gateway LEDs on page 10
■ SRX100 Services Gateway Boot Devices on page 13
■ SRX100 Services Gateway Power Supply on page 13
SRX100 Services Gateway Specifications
The SRX100 Services Gateway chassis is a rigid sheet metal structure that houses all
the other hardware components (see Figure 1 on page 6).
Table 4 on page 5 provides information on the physical specifications of the device.
Table 4: SRX100 Services Gateway Specifications
ValueSpecification
1.38 in. (35 mm)Chassis height
8.5 in. (216 mm)Chassis width
5.79 in. (147 mm)Chassis depth
1.86 lb (844 g)Chassis weight
No performance degradation to 10,000 ft (3048 m)Altitude
Normal operation ensured in temperature range of 32°F (0°C) to
104°F (+40°C)
Nonoperating storage temperature in shipping container: –40°F
(–40°C) to 158°F (70°C)
NOTE: The SRX100 Services Gateway operating temperature is 35
°C when installed in a Rack.
Temperature
SRX100 Services Gateway Specifications ■ 5
