Installation Overview for the SRX100 Services Gateway
After you have prepared your installation site, you are ready to unpack and install
the services gateway. It is important to proceed through the installation process in
the order shown in Table 14 on page 26:
Table 14: Installation Process Order for the SRX100 Services Gateway
For More Information, SeeProcessSteps
SRX100 Services Gateway Safety Requirements,
Warnings, and Guidelines on page 39
Review the safety guidelines.1
Site Preparation Checklist for the SRX100
Services Gateway on page 17
Verify that you have prepared your site for the
installation of the services gateway using the
checklist.
2
Unpacking the SRX100 Services Gateway on
page 31
Follow the instructions for unpacking the services
gateway and verify that the parts are received.
3
Preparing the SRX100 Services Gateway for
Rack-Mount Installation on page 35
Preparing the SRX100 Services Gateway for
Desk-Mount Installation on page 36
Preparing the SRX100 Services Gateway for
Wall-Mount Installation on page 37
Prepare the services gateway for installation.4
Installing the SRX100 Services Gateway in a
Rack on page 40
Installing the SRX100 Services Gateway on a
Desk on page 42
Installing the SRX100 Services Gateway on a
Wall on page 43
Install the services gateway.5
Connecting and Organizing Interface Cables to
the SRX100 Services Gateway on page 46
Connect cables to external devices.6
Grounding the SRX100 Services Gateway on
page 47
Connect the grounding cable.7
Powering On and Powering Off the SRX100
Services Gateway on page 48
Power on the services gateway.8
Related Topics Unpacking the SRX100 Services Gateway on page 31
General Site Guidelines for Installing the SRX100 Services Gateway on page 19
Preparing the SRX100 Services Gateway for Rack-Mount Installation on page 35
Preparing the SRX100 Services Gateway for Desk-Mount Installation on page 36
Preparing the SRX100 Services Gateway for Wall-Mount Installation on page 37
26 Installation Overview for the SRX100 Services Gateway
