Using the E-Plex Advanced ACS Software
3–36 PKG 3114 0106
E-Plex Advanced ACS User’s Guide
5. From the Buzzer Volume field, select a volume level by using the Up and Down arrows.
Note: The available buzzer volume levels range between zero (off) and three (loud);
the default is one (low).
6. From the Tamper Count field, select a tamper count value by using the Up and Down
arrows. The tamper count defines the number of concurrent times that an invalid PIN or
Card may be entered/presented before the lock goes into a temporary lockout mode.
Note: The available tamper count values range between three and nine; the default is
four attempts.
7. From the Tamper Shut Time field, select a tamper shut time by using the Up and Down
arrows. This is the temporary lockout or shutdown time after the tamper count limit has
been exceeded. A value of zero means that the lock will never shut down because of
illegal wrong-try attempts.
Note: The available tamper shut time values range between zero and 90. Zero means
the lock will never go into a tamper shutdown mode; the default is 30 seconds.
8. Select a Lock Model by clicking E5200 or E5700.
9. Select the Lock Function from one of the following options:
• Cylindrical or Mortise without Deadbolt
• Cylindrical with Privacy Thumbturn
• Mortise with Deadbolt
o With Privacy
o Residence Lock (in Passage Mode by Default)
• Exit Trim
Note: Refer to the separate “E-Plex 5X00 Lock Function Setup Guide” for instructions
on changing to the desired BHMA lock function.
10. Click Save. The software displays the updated Manage Doors window:
