KACO blueplanet 3.0 NX3 M2 KACO blueplanet 5.0 NX3 M2 KACO blueplanet 8.0 NX3 M2 KACO blueplanet 10.0 NX3 M2
KACO blueplanet 15.0 NX3 M2 KACO blueplanet 20.0 NX3 M2 Page 5
1.3 Choosing the installation location
Installation environment
1. Ensure that the inverter is installed out of the reach of children.
2. To ensure an optimal operation and a long service life, the temperature of the installation environment of the inverter
should be ≤ 40 °C.
3. T
o avoid direct sunlight, rain, snow and moisture on the inverter, we recommend to install the inverter at locations with
a protective roof. Do not completely cover the top of the inverter.
4. The installation conditions must be able to accommodate the weight and size of the inverter. The inverter is suitable for
mounting on a solid wall that is vertical or sloping backwards (max. 15°). It is not recommended to install the inverter on
a wall made of plasterboard or similar materials. The inverter may emit audible noises during operation.
Fig. 1: Device for outdoor installation
Fig. 2: Permissible installation location
5. To ensure adequate heat dissipation, the following clearances are recommended between the inverter and other
objects:
Fig. 3.1: Device for outdoor installation
Fig. 3.2: Lifting position (right side)
