3.1 Summary
Below you will find a summary of the most important components, which will then be
described on the following pages.
NO.
NAME
NO.
NAME
01
FRAME
16
MAIN OIL PUMP
02
FRONT COVER
17
VALVE OIL PUMP
03
SIDE COVER
18
DOUBLE GEAR PUMP
04
HYD. OIL TANK
19
OIL COOLER
05
FUEL TANK
20
AIR FILTER
06
REAR OUTRIGGER
21
ACCUMULATOR
07
FRONT OUTRIGGER
22
DEF TANK
08
NON BRAKE AXLE
23
ENGINE CONTROL PANEL
09
HOPPER
24
CONTROL PANEL
10
DELIVERY CYLINDER
25
LIMIT SWITCH
11
MAIN HYDRAULIC CYLINDER
26
CONTROL VALVE
12
ENGINE COOLER
27
EMERGENCY SWITCH
13
BATTERY
28
HYD. OIL GAUGE
14
DIESEL ENGINE
29
UEL GAUGE
15
SCR
30
B.K.T FOR TRACTION
