KCP 113 - Seal Housing Seal Set

KCP Heavy Industries Co., Ltd. Maintenance
7-21
► Take the swing lever (5) off the s-tube shaft.
► Unscrew the fastening bolt (9) from the seal housing
► Force the seal housing off by screwing the two jacking bolts into the jacking bores.
► Check the seals and O-rings in the seal housing for wear and replace these as
required.
7.10.2 Seal housing seal set
► Remove the o-ring.
► Remove the old seal set. It may be necessary to cut old seals.
