KCP 113 - Removing the S Tube Shaft Bearing (Seal Housing)

KCP Heavy Industries Co., Ltd. Maintenance
7-19
7.10.1 Removing the s tube shaft bearing (seal housing)
► Remove two grease lines on the retaining plate and the two grease lines on the
seal housing.
► Undo three fastening bolts (1) on the retaining plate (2) and remove the retaining
plate (2).
Environmental protection _________________________________________________
Catch the escaping hydraulic fluid in a suitable container and dispose of it in accordance
with the disposal regulations applicable for your region.
_______________________________________________________________________
