KCP 113 - Bite Type Fitting, Torque Specification

KCP Heavy Industries Co., Ltd Maintenance
7-4
Metric precision thread
DIMENSION(mm)
TORQUE RATING M x d (Nm)
M
W
8.8
10.9
12.9
M8 x 1.0
13
27
39
46
M10 x 1.25
17
52
76
90
M12 x 1.25
19
93
135
160
M12 x 1.5
19
89
130
155
M14 x 1.5
22
145
215
255
M16 x 1.5
24
225
330
390
M18 x 1.5
27
340
485
570
M20 x 1.5
30
475
680
790
M22 x 1.5
32
630
900
1050
M24 x 2.0
36
800
1150
1350
M27 x 2.0
41
1150
1650
1950
M30 x 2.0
46
1650
2350
2750
7.2.1 Bite type fitting, Torque specification
Bite type fitting
External diameter (mm)
M x D (Nm)
External diameter (mm)
M x D (Nm)
6
L
20
20
L
200
8
L
40
25
S
400
10
L
50
30
S
500
12
L
55
36
S
700
15
L
70
18
L
120
