KEISOKU GIKEN LOAD EDGE Series User Manual

Load Edge Series
Operations for Measurement Mode 73
Fig. 6-3-1 Voltage range setting - 1
After the knob is pressed first, MODE is displayed in the dot circle in the upper
figure. When the knob was pressed second, “Vr” is displayed. Turn the knob to select
“4V” or “30V” as shown below. Press ENT key or the knob to confirm the setting
selected.
Fig. 6-3-2 Voltage range setting – 2
Voltage range
Table. 6-3-1 Voltage range per model
The voltage range can be set only HIGH or LOW as fixed range.
(2) Current range setting
Press the rotary knob three times quickly.
Fig. 6-3-3 Operation to change current range - 1
After you press the knob once, MODE is displayed in the dot circle in the upper
Model
Range HIGH
Range LOW
ELZ-175
30V
4V
P
u
s
h
o
n
c
e
P
u
s
h
t
w
i
c
e
P
u
s
h
o
n
c
e
P
u
s
h
t
w
i
c
e
P
u
s
h
t
h
r
i
c
e
