Inspection
The Model 2016 was carefully inspected electrically and mechanically before shipment.
After unpacking all items from the shipping carton, check for any obvious signs of physical
damage that may have occurred during transit. (Note: There may be a protective film over the
display lens, which can be removed.) Report any damage to the shipping agent immediately.
Save the original packing carton for possible future reshipment. The following items are
included with every Model 2016 order:
• Model 2016 THD Multimeter with line cord.
• Safety test leads (Model 1751).
• Accessories as ordered.
• Certificate of calibration.
• Product Information CD-ROM that contains a PDF of the Model 2016 User's Manual.
If an additional manual is required, order the appropriate manual package. The manual
packages include a manual and any pertinent addenda.
Options and accessories
The following options and accessories are available from Keithley for use with the
Model 2016.
General purpose probes
Model 1754 Universal Test Lead Kit:
Consists of one set of test leads (0.9m), two spade
lugs, two banana plugs, two hooks, and two alligator clips.
Model 8605 High Performance Modular Test Leads:
Consists of two high voltage (1000V)
test probes and leads. The test leads are terminated with a banana plug with retractable sheath
on each end.
Model 8606 High Performance Probe Tip Kit:
Consists of two spade lugs, two alligator
clips, and two spring hook test probes. (The spade lugs and alligator clips are rated at 30V RMS,
42.4V peak; the test probes are rated at 1000V.) These components are for use with high
performance test leads terminated with banana plugs, such as the Model 8605.
The following test leads and probes are rated at 30V RMS, 42.4V peak:
Models 5805 and 5805-12 Kelvin Probes:
Consists of two spring-loaded Kelvin test probes
with banana plug termination. Designed for instruments that measure 4-terminal resistance. The
Model 5805 is 0.9m long; the Model 5805-12 is 3.6m long.
Model 5806 Kelvin Clip Lead Set:
Includes two Kelvin clip test leads (0.9m) with banana
plug termination. Designed for instruments that measure 4-terminal resistance. A set of eight
replacement rubber bands is available as Keithley P/N GA-22.
1-4 General Information
