Using SHIFT-CONFIG to configure stepping and scanning
From the SHIFT-CONFIG key combination, the minimum and maximum channels in the
scan list, the time between scans, and the reading count.
1. To configure stepping or scanning, perform the following:
2. Select the desired measurement function.
3. Press the SHIFT-CONFIG keys to access the step/scan configuration.
4. Select the first channel in the scan list (MINimum CHANnel) by using the , , ▲,
and ▼ keys and pressing ENTER.
5. Select the last channel in the scan list (MAXimum CHANnel) and press ENTER to
confirm.
6. The next selection is for timed scans. (This is the Timer control source in the trigger
model.) It sets a user-specified interval for starting scans. If you choose timed scans, the
Model 2016 prompts for a time interval:
00H:00M:00.000S
Use the , , ▲, and ▼ keys to select a time interval and press ENTER to confirm.
7. Next, you are prompted for a reading count (RDG CNT). This can be less than, equal to,
or greater than the scan list length (up to 1024). It is the number of readings that will be
stored in the buffer. The effects of these choices are further described in the scanning
examples.
8. Press ENTER when done to return to the normal display. Note that scanned readings are
always stored in the buffer, up to the setting for RDG CNT.
Measurement Options 3-23
