dBm calculation
dBm is defined as decibels above or below a 1mW reference. With a user-programmable
reference impedance, the Model 2016 reads 0dBm when the voltage needed to dissipate 1mW
through the reference impedance is applied. The relationship between dBm, a reference
impedance, and the voltage is defined by the following equation:
Where: V
IN
is the DC or AC input signal.
Z
REF
is the specified reference impedance.
NOTE Do not confuse reference impedance with input impedance. The input impedance of
the instrument is not modified by the dBm parameter.
If a relative value is in effect when dBm is selected, the value is converted to dBm then REL
is applied to dBm. If REL is applied after dBm has been selected, dBm math has REL applied
to it.
Configuration
To set the reference impedance, perform the following steps:
1. After selecting dBm, the present reference impedance is displayed (1-9999Ω):
REF: 0000
2. To change the reference impedance, use the and keys to select the numeric
position. Then use the ▲ and ▼ keys to select the desired value. Be sure to press ENTER
after changing the reference impedance.
NOTES dBm is valid for positive and negative values of DC volts.
The mX+b and percent math operations are applied after the dBm or dB math. For
example, if mX+b is selected with m=10 and b=0, the display will read 10.000 MXB
for a 1VDC signal. If dBm is selected with Z
REF
= 50Ω, the display will read 130MXB.
dBm = 10 log
V
2
IN
/Z
REF


1mW
---------------------------------
2-30 Basic Measurements
