1 Input connections
INPUT HI and LO Used for making DC volts, AC volts, 2-wire resistance measurements.
SENSE
Ω4 WIRE Used with INPUT HI and LO to make 4-wire resistance measurements.
HI and LO
2 TRIGGER LINK
One 8-pin micro-DIN connector for sending and receiving trigger pulses among other
instruments. Use a trigger link cable or adapter, such as Models 8501-1, 8501-2, 8502, 8504.
3 RS-232
Connector for RS-232 operation. Use a straight-through (not null modem) DB-9 cable.
4 IEEE-488
Connector for IEEE-488 (GPIB) operation. Use a shielded cable, such as Models 7007-1 and
7007-2.
5 Power module
Contains the AC line receptacle, power line fuse, and line voltage setting. The Model 2016
can be configured for line voltages of 100V/120V/220V/240VAC at line frequencies of 45Hz
to 66Hz.
6 INV/PULSE SOURCE OUTPUT
A BNC connector that provides an inverted sine wave or pulsed output for exciting
devices under test during distortion measurement or for general purpose use. This
connector also may provide a square wave pulse for triggering or synchronizing other
systems to the SOURCE OUTPUT sine wave.
7 SOURCE OUTPUT
A BNC connector that provides a sine wave output for exciting devices under test during
distortion measurement or for general purpose use.
Basic Measurements 2-7
