2600AS-901-01 Rev. B / September 2008 Return to Section Topics 19-123
Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
smuX.measure.Y
X = SMU channel (a or b)
Y = SMU measure function (v, i, iv, r, or p)
Where: v = voltage, i = current, r = resistance, p = power
Function Performs one or more measurements.
TSP-Link
accessibility
This function can be accessed from a remote TSP-Link node.
Usage There are three ways to use this function:
reading = smuX.measure.v()
reading = smuX.measure.v(rbuffer)
reading = smuX.measure.i()
reading = smuX.measure.i(rbuffer)
reading = smuX.measure.r()
reading = smuX.measure.r(rbuffer)
reading = smuX.measure.p()
reading = smuX.measure.p(rbuffer)
reading = smuX.measure.iv(ibuffer, vbuffer)
reading Returns the last reading of the measurement process.
rbuffer A reading buffer object where all the reading(s) will be stored.
ibuffer A reading buffer object where current reading(s) will be stored.
vbuffer A reading buffer object where voltage reading(s) will be stored.
Remarks • This function returns only the last actual measurement as reading. To use the additional
information acquired while making a measurement, a reading buffer must be used. If the
instrument is configured to return multiple readings when a measurement is requested, all
readings will be available in rbuffer if one is provided, but only the last measurement will be
returned as reading.
• The smuX.measure.iv function stores both current and voltage readings in respective buffers
(current and then voltage are stored in separate buffers).
• The smuX.measure.count attribute determines how many measurements are performed.
When using a buffer, it also determines the number of readings to store in the buffer.
Details See Reading Buffers in Section 7.
Also see smuX.nvbufferY, smuX.nvbufferY
Example Performs ten voltage measurements using SMU A and stores them in a buffer:
smua.measure.count = 10
smua.measure.v(smua.nvbuffer1)
