Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
KIHighC
The KIHighC factory script is made up of two functions: i_leakage_measure() and
i_leakage_threshold(). These functions are intended to be used when HighC mode is
active. Output is generally at a non-zero voltage prior to calling these functions. These functions
can also be used to step the voltage to zero volts in order to measure the leakage current.
Table 19-21
KIHighC TSP test script: i_leakage_measure()
TSP project name: KIHighC
TSP test script name: KIHighC
Function:
i_leakage_measure(smu, levelv, limiti, sourcedelay, measurei, measuredelay)
Description Performs a single current measurement.
Parameters
smu, levelv, limiti, sourcedelay, measurei, measuredelay
smu: SourceMeter instrument Channel (A or B).
levelv: Voltage level to step to.
limiti: Current limit setting for the voltage step.
sourcedelay: Delay to wait before lowering the current limit
for measurement.
measurei: Measure range for the current measurement.
Note the current limit is lower at this level and
it is presumed (because HIGHC mode is
active) the measure range will follow.
measuredelay: Delay to wait after lowering the current limit
before taking the measurement.
Return
values
imeas: The measured current.
Output
Data
The measured current.
Example
smua.source.levelv = 5 --charge the cap
smua.source.output = smua.OUTPUT_ON
delay(1)
imeas = i_leakage_measure(smua, 0, 1, 300e-3)
The parameters passed on to the i_leakage_measure() function are as
follows:
• smu = smua
• levelv = 0V
• limiti = 1A
• sourcedelay = 300ms
• measurei = 10 uA range
• measuredelay = 100 ms
The levels and delays will depend on the value and type of capacitor used.
