Series 2600A System SourceMeter® Instruments Reference Manual Section 22: Performance Verification
8. For the Model 2602A/2612A/2636A, repeat the above procedure for the other channel.
Output current accuracy
Series 2600A output current accuracy 100nA and higher
Follow the steps below to verify that the Series 2600A output current accuracy is within specified
limits.
NOTE An alternate procedure for 100nA current accuracy is shown in the
1nA to 100nA Output current accuracy procedure for the Model
2635A/2636A.
1. With the power off, connect the digital multimeter to the Series 2600A output terminals, as
shown in
Figure 22-2.
2. Select the multimeter DC current measuring function.
3. Select the Model 2602A/2612A/2636A single-channel display mode.
4. Press the Series 2600A SRC key to source current, and make sure the source output is
turned on.
5. Verify output current accuracy for each of the currents for the 1uA to 1A ranges listed in
Table 22-6 (Model 2601A/2602A), or Table 22-7 (Model 2611A/2612A), or Table 22-8
(Model 2635A/2636A). For each test point:
Table 22-4
Model 2601A/2602A voltage measurement accuracy limits
Model 2601A/2602A source
and measure range
1
Source voltage
2
Model 2601A/2602A voltage
reading limits
(1 year, 18°C–28°C)
100mV 90.000mV 89.8365 to 90.1635mV
1V 0.90000V 0.899665 to 0.900335V
6V 5.4000V 5.39819 to 5.40181V
40V 36.000V 35.9866 to 36.0134V
1. Measure range coupled to source range when simultaneously sourcing and measuring
voltage.
2. As measured by precision digital multimeter. Use closest possible value, and modify reading
limits accordingly if necessary.
Table 22-5
Model 2611A/2612A/2635A/2636A voltage measurement accuracy limits
Model 2611A/2612A/2635A/
2636A source and measure
range
1
Source voltage
2
Model 2611A/2612A/2635A/
2636A voltage reading limits
(1 year, 18°C–28°C)
200mV 180.000mV 179.748 to 180.252mV
2V 1.80000V 1.79929 to 1.80071V
20V 18.0000V 17.9923 to 18,0077V
200V 180.000V 179.923 to 180.077V
1. Measure range coupled to source range when simultaneously sourcing and measuring
voltage.
2. As measured by precision digital multimeter. Use closest possible value, and modify reading
limits accordingly if necessary.
