6-12 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 6: Range, Digits, Speed, Rel, and Filters Series 2600A System SourceMeter® Instruments Reference Manual
Figure 6-2
Median Filter
Remote filter programming
Filter commands
Table 6-6 summarizes filter commands. See Section 19 for more details on commands.
Filter programming example
The example below programs filter aspects:
• Filter type: moving average
• Filter count: 10
• Filter state: enabled
--Program count to 10
smua.measure.filter.count = 10
--Moving average filter type.
smua.measure.filter.type = smua.FILTER_MOVING_AVG
--Enable filter.
smua.measure.filter.enable = smua.FILTER_ON
Table 6-6
Filter commands
Commands* Description
smuX.measure.filter.count = count
smuX.measure.filter.enable = smuX.FILTER_ON
smuX.measure.filter.enable = smuX.FILTER_OFF
smuX.measure.filter.type = smuX.FILTER_MEDIAN
smuX.measure.filter.type = smuX.FILTER_MOVING_AVG
smuX.measure.filter.type = smuX.FILTER_REPEAT_AVG
Set filter count (1 to 100).
Enable filter.
Disable filter.
Select median filter type.
Select moving average filter type.
Select repeat average filter type.
* smuX = smua for the Model 2601A/2611A/2635A; smuX = smua (Channel A) or smub (Channel B) for the Model 2602A/2612A/
2636A.
Conversion
#1
#1
#1
Middle
value
reading
#1
Conversion
#2
#1
#1
Middle
value
reading
#2
Conversion
#3
#2
#1
Middle
value
reading
#3
A. Type - Median, Readings = 3
