2-22 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 2: DUT Test Connections Series 2600A System SourceMeter® Instruments Reference Manual
Figure 2-32
Model 2601A/2602A-1 SMU connections
Figure 2-33
Model 2636A SMU connections for the floating configuration shown in Figure 2-31
DUT
Low
10V
+ 
Chassis
External Source
Output low connected
to chassis
Source chassis connected to chassis
earth ground through the power cord
High
Keithley Model 2602A/2612A
Channel A
LO G
LO
HI G G G
HI
SS
Channel B
LOG
LO
HIGGG
HI
SS
HILO
Chassis
Screw
Low-Noise
Chassis Ground
Banana Jack
