2600AS-901-01 Rev. B / September 2008 Return to Section Topics 16-9

Series 2600A System SourceMeter® Instruments Reference Manual Section 16: LAN Concepts and Settings

Assigning the Method

Complete the following steps to select a method:

1. From the front panel, press MENU > LAN > CONFIG > METHOD.

2. Select one of the following methods and then push the navigation wheel to enter the

desired method:

•Press AUTO.

•Press MANUAL. The LAN CONFIG menu is shown.

3. (Optional) Press Exit to return to the LAN CONFIG menu. CONFIG blinks on the front

panel.

4. Turn the navigation wheel one click to the left and then push-in to select

APPLY_SETTINGS.

5. Select YES.

Setting the IP address

Note the following:

• Contact your IT department to secure a valid IP address for the instrument when placing

the instrument on a corporate network.

• The IP address does not need to be manually set if the method is set to AUTO.

A direct connection to the PC can also be configured. See Establishing a point-to-point connection

for more information.

Setting the subnet mask

Note the following:

• Contact your IT department to secure a valid subnet mask for the instrument when

placing the instrument on a corporate network.

• The subnet mask does not need to be manually set if the method is set to AUTO.

A direct connection to the PC can also be configured. See Establishing a point-to-point connection

for more information.

Understanding the domain name system

The Domain Name System (DNS) lets you type a domain name in the address bar to connect to

the instrument. The DNS removes the requirement to memorize the IP address, instead you only

need to know the domain name.

Example:

Series2600A.yourcompany.com

Contact your IT department to learn more about DNS.

NOTE If a DNS server is not part of the LAN infrastructure, then this setting

is not used.
