Section 11: Display Operations Series 2600A System SourceMeter® Instruments Reference Manual
Display functions and attributes
The display functions and attributes are used to perform the display operations covered in this
section.
Table 11-1 lists each display function/attribute (in alphabetical order) and cross references
it to the section topic where the function/attribute is explained.
Section 19 provides additional information on the display functions and attributes.
Display features
Display screen
The Keithley Instruments Series 2600A System SourceMeter
®
instrument can display source-
measure values and readings or user defined messages. The display screen options include the
following:
• Source-measure, compliance screens:
• Display source and compliance values, and measure readings for SMU A.
• Display source and compliance values, and measure readings for SMU B (Models 2602A/
2612A/2636A only).
• Source-measure screen – Display source values and measure readings for SMU A and SMU
B (Models 2602A/2612A/2636A only).
• User screen – Display user-defined messages and prompts.
The display.screen attribute is used to select the display screen:
display.screen = displayId
where: displayId is set to one of the following values or names:
0 or display.SMUA
Table 11-1
Cross referencing functions/attributes to section topics
Function/Attribute Section Topic
display.clear Clearing the display
display.getannunciators Indicators
display.getcursor Cursor position
display.gettext Displaying text messages
display.input Capturing key-press codes
display.inputvalue Parameter value prompting
display.loadmenu.add
display.loadmenu.delete
Load test menu
display.locallockout LOCAL lockout
display.menu Menu
display.prompt Parameter value prompting
display.screen Display screen
display.sendkey Sending key codes
display.setcursor Cursor position
display.settext Displaying text messages
display.smuX.digits Display resolution
display.smuX.measure.func Measurement functions
display.trigger.clear
display.trigger.wait
Key-press codes
