6-2 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 6: Range, Digits, Speed, Rel, and Filters Series 2600A System SourceMeter® Instruments Reference Manual
Overview
The documentation in this section provides detailed information on characteristics and script
programming for each of the following functions:
• Range
• Digits
• Speed
• Rel
• Filters
Range
The selected measurement range affects the accuracy of the measurements as well as the
maximum signal that can be measured. Note that dashed lines are displayed (for example, --.----
µA), to indicate that the previous measurement is not recent. This usually happens when a change
occurs such as selecting a different range.
Available ranges
Table 6-1 lists the available source and measurement ranges for the Keithley Instruments Series
2600A System SourceMeter
®
instruments.
Table 6-1
Source and measurement ranges
Model 2601A/2602A Model 2611A/2612A Model 2635A/2636A
Voltage Ranges Current Ranges Voltage Ranges Current Ranges Voltage Ranges Current Ranges
100mV
1V
6V
40V
100nA
1μA
10μΑ
100μΑ
1mA
10mA
100mA
1A
3A
200mV
2V
20V
200V
100nA
1μA
10μΑ
100μΑ
1mA
10mA
100mA
1A
1.5A
10A
1
200mV
2V
20V
200V
100pA
2
1nA
10nA
100nA
1μA
10μΑ
100μΑ
1mA
10mA
100mA
1A
1.5A
1. 10A range available only in pulse mode.
2. 100pA range only in measure.
