5-6 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 5: High-Capacitance Mode Series 2600A System SourceMeter® Instruments Reference Manual
-- limiti = 1A
-- sourcedelay = 300ms
-- measurei = 10uA range
-- measuredelay = 100ms
NOTE Adjust the voltage level and source delays based on the value and
type of capacitor along with the magnitude of the voltage step and
the current measure range.
Figure 5-1
Enabling high-capacitance mode
5V
levelv = 5
Source delay
limit = 1A levelv = 0
Lower limit to 10mA
Measure delay
Measurement
0V
Note: Not drawn to scale
