19-144 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 19: Remote Commands Series 2600A System SourceMeter® Instruments Reference Manual
smuX.trigger.measure
smuX.trigger.initiate
X = SMU channel (a or b)
Function Initiates a sweep operation.
TSP-Link
accessibility
This function can be accessed from a remote TSP-Link node.
Usage smuX.trigger.initiate()
Remarks • This function causes the SMU to clear the four trigger model event detectors and enter its trigger
model state machine.
• To perform source actions during the sweep, it is necessary to configure and enable one of the
sweep source actions (smuX.trigger.source.linearY, smuX.trigger.source.listY,
or smuX.trigger.source.logY) and measure actions (smuX.trigger.measure.Y) prior
to calling this function.
• To perform measure actions during the sweep it is necessary to configure and enable a sweep
measurement action before calling this function.
• This function initiates an overlapped operation.
smuX.trigger.measure.action
X = SMU channel (a or b)
Attribute Enables or disables measurements during a sweep.
Default smuX.DISABLE
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage action = smuX.trigger.measure.action -- Reads measure action.
smuX.trigger.measure.action = action -- Writes measure action.
action The sweep measure action.
Remarks • action can be set to one of the following values:
smuX.DISABLE: Do not make measurements during the sweep.
smuX.ENABLE: Make measurements during the sweep.
Note: When setting the action to smuX.ENABLE, the measurement needs to be configured with
one of the smuX.trigger.measure.Y functions.
Also see smuX.trigger.measure.Y
smuX.trigger.measure.set
X = SMU channel (a or b)
Function Sets the measure event detector to the detected state.
TSP-Link
accessibility
This function can be accessed from a remote TSP-Link node.
Usage smuX.trigger.measure.set()
Remarks • This function sets the measure event detector to the detected state.
