Keysight Technologies 16861A - Performance Test Record

Keysight 16860 Series Portable Logic Analyzer Service Guide 77
Testing 16860 Performance 3
Performance Test Record
LOGIC ANALYZER MODEL NO.: 16861A, 16862A, 16863A, 16864A
Logic Analyzer Serial No. Work Order No.
Date: Recommended Test Interval - 2 Year/4000 hours
Recommended next testing:
TEST EQUIPMENT USED
Pulse Generator Model No.
Pulse Generator Serial No.
Pulse Generator Calibration Due Date:
MEASUREMENT UNCERTAINTY
Clock Rate
Pulse Generator Frequency Accuracy:
81134A: ±0.005% of setting.
Approx. Cabling Accuracy
±0.005% of setting.
2.01% = ±0.010% Uncertainty + 2% Test Margin.
Setting
Base option: (should be tested to the Option 700 level at the service
center)
Option 700:
• 700 MHz + 2% = 714 MHz (Single Clock mode)
• 350 MHz + 2% = 357 MHz (Multiple Clocks mode)
TEST RESULTS
Logic Analysis System Self-Tests (Pass/Fail):
TEST RESULTS - Maximum State Data Rate
Mode: Multiple Clocks (Both Edges)
Data Rate
(Spec)
(Mb/s)
Generator Frequency
(MHz)
Measured
Data Rate
(Mb/s)
Pod 1 Clock 700
Pod 2 Clock 700
Pod 3 Clock 700
Pod 4 Clock 700
