Configuration and Programming
P/N 06-237058-001 3-37 February 2012
FOOTNOTES (Figure 3-29):
3 Battery Disp Enable. Set the Display to Show the Standby-Battery Condition. Purpose: To
replace the "Normal" message on the display with the standby-battery charging voltage and
current. Battery Voltage 25.5V. Battery Current 0.50 A. If the control unit is restarted due to a
configuration change or power cycle, this option must be re-enabled. The display will have the
following typical appearance:
4 Battery Disp. Disable Set the Display to Not Show the Standby-Battery Condition. Purpose:
To replace the standby-battery charging voltage and current with the "Normal" message on the
display.
41 Supervise Battery. Enable Battery Supervision. Purpose: To disable and restore battery
supervision that was disabled using the “Battery Configuration” menu function.
PS: 25.5 V 1 mA 02:15 PM 07/02/04
North Communications Center
