Kidde Fire Systems ARIES NETLink User Manual

Configuration and Programming
February 2012 3-36 P/N 06-237058-001
Figure 3-29. ARIES NETLink Set Menu Functions (Cont’d - Fig. 11 of 18)
2. BATTERY DISPLAY
1. Battery Disp Enable 
2. Battery Disp Disable 
3. SET
Cont’d
*
*
6. OUTPUTS/BACKPLANE-
>2:BACKPLANE CONFIG->3:CITY TIE
6. OUTPUTS/BACKPLANE->2:BACKPLANE
CONFIG -> 4:PMU/BATTERY
BACKPLANE CONFIGURATION
PRESS '0' TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
BACKSPACE TO EXIT THE CONFIG
ENTER MODULE LOGICAL ADDRESS : __ 
PMU #
OWNER LOCATION:
*__________________________________
PRESS ‘0’ TO CHANGE SETTING
PRESS ENTER TO VIEW NEXT SETTING
PMU #
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
After final parameter, the following appears
PMU
CURRENT VALUE
OWNER LOCATION:
PMU Module owner location
BACKPLANE CONFIGURATION
PRESS '0' TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
BACKSPACE TO EXIT THE CONFIG
CITY TIE
OWNER LOCATION:
*__________________________________
PRESS ‘0’ TO CHANGE SETTING
PRESS ENTER TO VIEW NEXT SETTING
CITY TIE
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
After final parameter, the following appears
CITY TIE
CURRENT VALUE
OWNER LOCATION:
City Tie Module owner location
1:PMU SETTINGS
3. BATT REPLACE DATE
OLD REPLACEMENT DATE (MMDDYY): mmddyy
NEW REPLACEMENT DATE (MMDDYY): ______

4. SUPERVISE BATTERY
BATTERY CONFIGURATION
PRESS '0' TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
BACKSPACE TO EXIT THE CONFIG
BATTERY CONFIGURATION
USE SCROLL FOR OPTIONS, ENTER TO SELECT
CIRCUIT:
DISABLE
PRESS ‘0’ TO CHANGE SETTING
BATTERY CONFIGURATION
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
PMU
CURRENT VALUE
SUPERVISE BATTERIES
YES
6. OUTPUTS/
BACKPLANE-
>2:BACKPLANE
CONFIG ->
5:DACT
Figure 3-34
3
4
41
