Kidde Fire Systems ARIES NETLink User Manual

Configuration and Programming
P/N 06-237058-001 3-35 February 2012
Figure 3-28. ARIES NETLink Set Menu Functions (Cont’d - Fig. 10 of 18)
3. SET
Cont’d
*
*
6. OUTPUTS/BACKPLANE-
>2:BACKPLANE CONFIG->1:R-NAC
6. OUTPUTS/BACKPLANE-
>2:BACKPLANE CONFIG-> 2:RELAY
BACKPLANE CONFIGURATION
PRESS '0' TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
BACKSPACE TO EXIT THE CONFIG
ENTER MODULE LOGICAL ADDRESS : __ 
RELAY MODULE # CIRCUIT: #1
CURRENT VALUE
CIRCUIT OWNER LOCATION
RELAY MODULE # CIRCUIT: # 1
CIRCUIT OWNER LOCATION
*_________________________________
PRESS ‘0’ TO CHANGE SETTING
PRESS ENTER TO VIEW NEXT SETTING
RELAY MODULE # CIRCUIT: #
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
After final parameter, the following appears
RELAY MODULE #
CURRENT VALUE
OWNER LOCATION:
Relay Module owner location
BACKPLANE CONFIGURATION
PRESS '0' TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
BACKSPACE TO EXIT THE CONFIG
EXPANSION R-NAC
ENTER MODULE LOGICAL ADDRESS : __

R-NAC # CIRCUIT: #1
CURRENT VALUE
CIRCUIT OWNER LOCATION
R-NAC # CIRCUIT: #1
CIRCUIT OWNER LOCATION
*_________________________________
PRESS ‘0’ TO CHANGE SETTING
PRESS ENTER TO VIEW NEXT SETTING
RNAC MODULE #
CURRENT VALUE
OWNER LOCATION:
RNAC Module owner location
R-NAC MODULE: #
OWNER LOCATION
*_________________________________
PRESS ‘0’ TO CHANGE SETTING
R-NAC # CIRCUIT: #2
CURRENT VALUE
CIRCUIT OWNER LOCATION
R-NAC # CIRCUIT: #3
CURRENT VALUE
CIRCUIT OWNER LOCATION
Shows same settings
for Circuit 3
Shows same settings
for Circuit 2
RELAY MODULE: #
OWNER LOCATION
*_________________________________
PRESS ‘0’ TO CHANGE SETTING
Shows same settings can be seen for
Circuit 2,3 and 4.
RNAC MODULE # CIRCUIT: #
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
After final parameter, the following appears
