Kidde Fire Systems ARIES NETLink

Configuration and Programming
February 2012 3-48 P/N 06-237058-001
Figure 3-39. ARIES NETLink Test Menu Functions (Cont’d - Fig. 3 of 5)
4. TEST
Cont’d
1. Activate 2. Deactivate 
6. Outputs Test
1: NAC 1 * 
2: NAC 2 * 
3: R-NAC 1 * 
4: R-NAC 2 * 
1. Activate 2. Deactivate 
1. Activate 2. Deactivate 
1. Activate 2. Deactivate 
5: Relay 1 * 
6: Relay 2 * 
7: Relay 3 * 
8: Trouble Relay * 
1. Activate 2. Deactivate 
1. Activate 2. Deactivate 
1. Activate 2. Deactivate 
1. Activate 2. Deactivate 
1: ON BOARD CIRCUIT
2. BACKPLANE CIRCUIT
3. LAM/ATM
4. SLC OUTPUTS
5. RRM GROUP
Enter RRM Group Number * (1-7) 
1. Activate 2. Deactivate 
SLC Output Devices
ENTER SLC MODULE NUMBER (1-8) _ 
Activate 2. Deactivate 
SLC Devices From *__ to ___ (1-255)
1. Activate 2. Deactivate 
6. SLC OUTPUT GROUP
Enter SLC Group Number * (1-7) 
1. Activate 2. Deactivate 
*
1. LAM
ENTER LAM ADDRESS (1-16)___ 
2. ATM
ENTER ATM NUMBER (1-16)___ 
Figure 3-41
ENTER OUTPUT RANGE (01-16):__TO__ 
1:ACTIVATE 2:DE-ACTIVATE 3:PULSE 
1:DEFAULT 2:YELLOW 3:RED 
ENTER OUTPUT RANGE (01-16):__TO__ 
1:ACTIVATE 2:DE-ACTIVATE 3:PULSE 
6
*= Level-2 (Installer) Password required .
8
7
