Configuration and Programming
P/N 06-237058-001 3-49 February 2012
FOOTNOTES (Figure 3-39):
6 On Board Circuit. Activate Control-Unit-Based Outputs.
Purpose: To manually activate control-unit outputs during system testing to confirm proper
operation.
6 On Board Circuit. De-Activate Control-Unit-Based Outputs.
Purpose: To manually de-activate control-unit outputs that were activated during system testing.
7 On Board Circuit. Activate or De-Activate Control Modules (i.e., as AO, ASM or RRM).
Purpose: To manually activate or de-activate one or more control modules during system testing to
confirm the proper operation of control functions via AOs, NAC operation via ASMs or RRMs.
Note: All control modules must be manually de-activated via a menu operation or a system reset
before the system can be returned to normal operating condition.
CAUTION
There is no indication at the control unit that an output is activated. Be sure to de-activate
the output after proper operation has been confirmed.
Ensure that the outputs will not activate suppression systems or critical facility
operations such as computer power. Physically disconnect all agent-release and pre-
action-sprinkler circuits and bypass all affected power-off circuits before activating any
outputs if the outputs are activating suppression systems or are shutting off power.
Restore the system to normal operating condition at the conclusion of all output
activation and any other functional tests.
CAUTION
There is no indication at the control unit that an output is activated. Be sure to de-activate
the output after proper operation has been confirmed.
Ensure that the outputs will not activate suppression systems or critical facility
operations such as computer power. Physically disconnect all agent-release and pre-
action-sprinkler circuits and bypass all affected power-off circuits before activating any
outputs if the outputs are activating suppression systems or are shutting off power.
Restore the system to normal operating condition at the conclusion of all output
activation and any other functional tests.
CAUTION
There is no indication at the control unit that an output is activated. Be sure to de-activate
the output after proper operation has been confirmed.
Ensure that the control modules are not activating suppression systems or controlling
critical facility operations such as computer power. Physically disconnect the wiring to all
agent-release and pre-action-sprinkler circuits and bypass all affected power-off circuits
before activating any control modules if the control modules are activating suppression
systems or are shutting off power. Restore the system to normal operating condition at
the conclusion of all control-module activations and any other functional tests.
