Kidde Fire Systems ARIES NETLink User Manual

Troubleshooting
February 2012 7-26 P/N 06-237058-001
ATMAddr Not Registered On The control unit has not been set up to
expect the ATM at ATM RS-485 circuit
address Addr.
• Register the ATM if part of system
configuration. See Paragraph . This
procedure is insufficient. The
following procedure must also be
conducted.
• Upload a new application program
that includes the previously
unregistered ATM.
• De-register the ATM if not part of
system configuration. See Paragraph
3-2.5.2.4.55.
• Check the 24 Vdc power (Terminal
Block TB3)and RS-485
communications wiring (Terminal
Blocks TB1 and TB2) from the
control unit to the ATM
• Ensure that the ATM Address Switch
S1 is set correctly.
• Refer to ATM Installation Manual, P/N
06-236179-002.
ATMAddr PSU Fault On A loss of 24 Vdc power at Terminal
Block TB3 or an open circuit in the
monitoring circuit from the ATM's "PS
Flt" and "Com" terminals to the
normally-closed trouble contacts of its
associated remote power supply
• Refer to ATM Installation Manual, P/N
06-236179-002.
• Check for 24 Vdc power at ATM
Terminal Block TB3.
• Look for discontinuity in wiring to
remote-power-supply trouble
contacts. Jumper these terminals if
you are using the ARIES NETLink
Control Unit to power the ATM.
• Check for trouble with third-party
remote power supply.
ATMAddr Reset Input Fault On An open circuit in wiring from the
ATML's "Reset" input terminal to the
associated annunciator's reset switch.
ATM-L address is Addr.
• Refer to ATM Installation Manual, P/N
06-236179-002.
• Look for discontinuity in wiring to
reset switch
• Check for missing 10k end-of-line
resistor.
ATMAddr Silence Input Fault On An open circuit in wiring from the
ATML's "Silence" input terminal to the
associated annunciator's alarm-silence
switch. ATM-L address is Addr.
• Refer to ATM Installation Manual, P/N
06-236179-002.
• Look for discontinuity in wiring to
alarm-silence switch
• Check for missing 10k end-of-line
resistor.
ATMAddr Silenced Output Fault
On
An open circuit in wiring from the
ATML's "Silence" output terminal to the
associated annunciator's alarm-silence
LED. ATM-L address is Addr.
• Refer to ATM Installation Manual, P/N
06-236179-002.
• Look for discontinuity in wiring to
alarm-silence LED (if used)
• Check for missing 20k supervising
resistor if alarm-silence LED not
used
Table 7-7. ATM Events
ATM Events
Error Message Probable Cause Corrective Action
