Kidde FX-64

Chapter 3: System operation
140 P/N 3102352-EN • REV 005 • ISS 28DEC18
ID
Event description
095
Fw Dwnld in Progress: Firmware
update is successfully initiated from
the panel and firmware update utility
096
Fw Download Aborted: Firmware
update is aborted due to connectivity
loss (or) user has aborted download
from either panel or update utility
097
Fw Download Failed: Firmware
update failed to store the Image.bin
into panel flash memory
098
Fw Download Completd: Firmware
update is successfully completed
099
NAC 1 trouble: An open or short was
detected on NAC 1 or there is a
problem with the EOL
100
NAC 2 trouble: An open or short was
detected on NAC 2 or there is a
problem with the EOL
101
NAC 3 trouble: An open or short was
detected on NAC 3 or there is a
problem with the EOL
102
NAC 4 trouble: An open or short was
detected on NAC 4 or there is a
problem with the EOL
103
Printer trouble: The printer is either
offline, out of paper, or disconnected
104
Annunciator 1 trouble: An open or
short was detected on annunciator 1
105
Annunciator 2 trouble: An open or
short was detected on annunciator 2
106
Annunciator 3 trouble: An open or
short was detected on annunciator 3
107
Annunciator 4 trouble: An open or
short was detected on annunciator 4
108
Annunciator 5 trouble: An open or
short was detected on annunciator 5
109
Annunciator 6 trouble: An open or
short was detected on annunciator 6
110
Annunciator 7 trouble: An open or
short was detected on annunciator 7
111
Annunciator 8 trouble: An open or
short was detected on annunciator 8
ID
Event description
112
Zone 1 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone1)
113
Zone 2 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected on
zone 2)
114
Zone 3 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone 3)
115
Zone 4 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone 4)
116
Zone 5 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone 5)
117
Zone 6 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone 6)
118
Zone 7 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone 7)
119
Zone 8 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone 8)
120
Zone 9 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone 9)
121
Zone 10 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone
10)
122
Zone 11 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone
11)
123
Zone 12 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone
12)
124
Zone 13 (active, trouble, disable,
prealarm, alarm verify, maintenance
alert, or test was detected in zone
13)
